Core Features

Support 100+ Currency
Support Customize for your need

Controled By REST API
Compatible with All OS System

2.4G WIFI Connection
RJ45 Connection

Export Daily and Moth Report
All Transaction Log

Counterfeit detection，Automatic change dispensing
Optional electronic lock

Modular design
front and rear doors and a top flip cover

Rejects counterfeit notes and coins

✔

✔

✔

Banknote number of the cashbox

600

1000

1000

Banknotes recycler capacity

40notes, mixed note of any denomination

80notes, mixed note of any denomination

680 notes, 4 recyclers x 70, 400 replenish

Banknote validation speed

4 s/banknote

2 s/banknote

2 s/banknote

Banknote dispensing speed

4 s/banknote

3.2 s/banknote

1.5 seconds. bundles of up to 10 banknotes

Coin recycler capacity

1500 mixed of any denomination

1500 mixed of any denomination

1500 mixed of any denomination

Coin number of the coinbox

450

450

1000

Coin validation speed

4 coins/s

4 coins/s

4 coins/s

Coin dispensing speed

12 coins per second

12 coins per second

12 coins per second

Refill Banknote box

✘

✘

400 mixed notes

Remote online debug

✔

✔

✔

Dimensions

42*42*63

42*41*63

42*41*67

Built-in PAYMENT SYTEM

✔

✔

✔

Weight

34KG

36.5 KG

50.8 KG

The machine supports three operating modes: Standalone ， REST API mode， Vending Machine.

Standalone Mode
1. The Cashier input the pay money on the touch screen ,then insert cash. At the same time the machine displays the real-time amount inserted.
2. The machine determines whether change is needed and dispenses it accordingly.
3. Once the full amount is received, the machine confirms the transaction
4. The transaction is completed. Optionally print a receipt

 REST API mode
1. The POS system or another system informs the machine of the transaction amount via REST API.
2. The machine prompts the customer to insert cash and displays the real-time amount inserted on the screen.
3. The machine determines whether change is needed and dispenses it accordingly.
4. The POS system retrieves the transaction completion information via REST API.
5. The transaction is completed.

Vending Machine Mode
1. Customer selects the desired product.
2. Customer proceeds with the payment.
3. The system prints a receipt.
